Process Cranes for The Prefabricated Industry

Process Cranes for The Prefabricated Industry, Suitable in almost working environment, Popular sale Model, Welcome to choose.
Double Girder Bridge Overhead Crane Universal LH Model
Double girder overhead crane capacity:LH3 - LH32/5 ton
Overhead crane span: 6m - 31.5 m
Overhead crane lift height: 3m - 60m
Working Temperature: -25 to 40°C
Availability:
Quantity:
  • LH Middle duty universal model
  • Tavol
  • 040

Product Description

Chinese Industrial Overhead crane for sale

Prefabricated components refer to various components manufactured by pre-forming methods.

The pre-molded components are usually completed in professional factories and then transported to the site for use. This concept is mainly used in the field of construction. According to the material properties, it can be divided into steel structure prefabricated components, wooden structure prefabricated components, concrete prefabricated components, and stone prefabricated components.

Among them, the concept of prefabricated concrete components is the most widely used. In the construction field, prefabricated components are usually equivalent to reinforced concrete precast components or precast concrete (PC). No Matter What Kinds Prefabricated Components, it is too heavy to handling with, That is why you need the Overhead Cranes or Gantry Cranes to Handling them.

QQ图片20200316161556 - 副本

01- Double Girder Bridge Overhead Crane Structure:

LH Model double girder overhead bridge crane is suitable for light and middle grade.It is composed of box type bridge frame, lifting trolley, crane traveling mechanism and electrical system. It employs fixed electric hoist, which is fitted on trolley frame as the hoisting mechanism.

QQ图片20200316161556 - 副本

02- Double Girder Bridge Overhead Crane Specification:

SI

Descriptions

Reference Data

1

Double girder overhead crane capacity

3 ton, 5 ton, 10 ton, 15 ton, 20 ton, 20/5 ton, 32 ton, 32/5 ton

2

Double girder overhead crane Span

6 - 31.5 meter

3

Double girder crane Lifting height

3- 60 meter

4

Double girder bridge crane Work duty

A4/M4; A5/M5

5

Overhead Crane Control method

Remote control & Pendant Control

6

Electrical parts

CHINT or Schneider

7

Overhead Crane Motors

Chinese Nanjing brand

8

Overhead Crane Bearings

Chinese famous brand "HRB"

9

Overhead Crane Hook

Forged hook with safety lock

10

Overhead Crane Hoist Lifting speed

0-8M/Min (8/0.8m/min)

11

Crane hoist Traverse speed

0-20M/Min

12

Double girder Bridge Crane Long travelling speed

0-20M/Min (30m/min)

13

Variable frequency drives

Optional

14

Maintenance platform

Included
