BMH Model Electrical Semi Girder Gantry Crane

BMH Model Electrical Semi Girder Gantry crane
Overhead gantry crane single girder MH Model for indoors or outdoors factory and workshop
gantry crane capacity: MH1- 20ton
gantry crane span: 3- 40 m
gantry lift height:3- 20m
Run way length: 10- 200m
Availability:
Quantity:
  • BMH Model Electrical Semi Girder Gantry crane
  • Tavol
  • 026

Product Description

BMH Model Electrical Semi Girder Gantry crane

 is used together with CD MD Model electrical hoists, It is a track travelling small and medium-sized crane, Its proper lifting weight is 2 to 16 tons, proper span is 5 to 20 meters,

its proper working temperature is -20 ℃ to 40℃.

10t semi girder gantry crane

Electrical Semi Girder Gantry crane

is a universal crane widely used at open ground and warehouses to load and unload or grab materials.

Its has two controlling methods, namely ground controlling and cabin controlling.

overhead gantry crane

Electrical Semi Girder Gantry crane

 is a kind of light type crane, commonly used in modern production. In workshops where part utilization of shop bay is required (as in a tool room attached to a press shop), a Semi-Goliath/Gantry Crane is used. In such a configuration, one side end truck of the crane will travel on the regular gantry rail while the opposite end truck will travel on a rail mounted typically on the ground or at a lower elevation.


Model Optional



SWL

(t)

Span (m)

Lifting Height
(m)

Work

Duty

Lifting Speed
(m/min)

Trolley Travelling Speed
(m/min)

Crane

Travelling Speed
(m/min)

Total Power (kw)

Rail

2

10~20

6

A4/M4

8

20

20

380V
50HZ

24kg/m

3

10~20

6

8

20

20

5

10~20

6

8

20

20

38kg/m

10

10~20

6

7

20

30

single semi girder crane

Application:

This crane is mainly used in steel stock yard, mine, the concrete industry, warehouse, factory, harbor and ship building, etc.



Features:

Compact dimensions, low weight, easy to operate and easy to maintain, steady performance, safety, less wastage, low cost and so on.

Compared with the electric single-girder gantry crane,it is saving the investment and space.



Optional features:

1. Variable speed through VVF Drive

2. Soft starter

3. Wireless Radio Remote control

4. Waterproof.

5. Remote control

steel gantry crane
