Good Quality Curtis Controller 1.5 Ton 2ton 2.5ton 3tons 3.5t 4 Wheel Electric Forklift for Sale

Availability:
Quantity:
  • FB
  • TAVOL
  • 84271090

Product Description

 Product Information

Tavol forklift driving cab has excellent all round visibility, adjustable full suspension seat,ergonomically laid out levers and pedals, which can bring you more convenient and comfortable operation experience, improve the comfort of your work.

QQ20210421091421



Model

FB20

Rated Loading Capacity(kg)

2000

Load center(mm)

500

Drive Form

Electric

Tyre type

Solid tire

Driving way

Seat

Fork Lifting Height(mm)

5000

Max.Lifting height

3000mm

Free lifting height

Full free

Mast inclination

5/10

Wheel Base(mm)

1450

Wheel distance

Front (mm)

920


Back(mm)

928

Min. Ground Clearance(mm)

106

 Overall dimensions

Length (no Fork)(mm)

2160


Width(mm)

1100


Height

(Door Frame Indented)(mm)

1933

Height from ground to overhead guard(mm)

2040

Seat height

1036mm

Minimum turning radius

1650mm

Minimum right-angle stacking channel width

2450mm

Fork size

40x100x1070mm

Cylinder

45mm

Gear pump

14 ml/r

Tire

Front tire

18*7-10


Rear tire

4.00-8

 Motor

Walking motor

6kw


Maximum speed of walking motor

3500 rad/min


Oil pump motor

5kw


Maximum speed of oil pump motor

2000 rad/min

Battery

72v/160ah

Charger

Input voltage

220v/380v


Current

30a


Charging time

8-10h

Electric control

72/450V/A

Transmission

Hydraulic power steering




4

  Cetificate and Package about Tavol Forklift



Q`D[G]X){H]Q%[%HS7_)F~B

package 2

About our company

5

 Feeback from customer

6

Contact us as below:

Ms.Mika

sls88@tavolgroup.com

Whatsapp/Wechat:+86 13287635200
