China Famous Paper Roll Clamp Hinged Fork Block Clamp CPC CPCD35 3.5TON Diesel Forklift

Tavol forklift adopts the streamline design that makes the appearance more pleasing,using domestic well-known engine brand which is powerful, dependable, easy to service ,and with low emissions and fuel consumption.Our forklift can reduce your cost,provide greater productivity and profitability for you.
Availability:
Quantity:
  • CPC/CPCD

  • TAVOL

  • 84272090

Product Description

China Famous Paper Roll Clamp Hinged Fork Block Clamp CPC CPCD35 3.5TON Diesel Forklift


Product Description

Tavol forklift driving cab has excellent all round visibility, adjustable full suspension seat ,ergonomically laid out levers and pedals, which can bring you more convenient and comfortable operation experience, improve the comfort of your work.

photobank (3)
Specification
Model
CPC32/CPCD32
CPC36/CPCD36
Rated Load(kg)
3200
3600
Load center(mm)
500
500
Power unit
Diesel
Diesel
Lifting speed(no
load/full)mm/h
505/475
505/450
Max traveling(full/no load)km/h
18/20
18/20
Max lifting height (mm)
3000
3000
Tilt range
6/12
6/12
Min.turning radius(mm)
2530
2540
Min.ground clearance(mm)
135
135
Overall size
Length(with fork)mm
3970
4000
Width(mm)
1230
1230
Height(mast retract)
2110
2110
Height(mast extened)
4270
4270
Height from ground to overhead guard(mm)
2105
2105
Front overhang(mm)
465
465
Wheelbase(mm)
1775
1775
Wheel distance
front (mm)
1000
1000
back(mm)
970
970
Tire
Front tire
28*9-15
28*9-15
Rear tire
6.50-10
6.50-10
Self weight(kg)
4250/4290
4660/4700
Fork width(mm)
122
122
Fork thickness(mm)
45
45
Back rest height(mm)
1225
1225
Standard fork length(mm)
1220
1220
Motor
Rated ourput(kw)
36.8
36.8
Rated torque(nm)
156
156
Transmission
Mechanical/Hydraulic
Mechanical/Hydraulic
Product Images

detail 3

New suspension adjustable seat

More comfortable when working

detail 1

Operating Steering wheel and function

operation bar Enlarge working space

detail 2

Full set of LED lightSave electricity, high

strength, longer service life.


detail 4

Wear-resistant solid tireIncrease the ability

of forklift to adopt different roads and

working environment.




Packing & Delivery

Sea worthy package type, if one set, we will load it into plywood case by LCL;

 If more than 2 sets, we will choose use 20GP container or 40GP container to load them.

They will be fixed strongly in container for suitable sea shipping.


International Certification
ISO9001 Quality Certificate
Company Profile
Shandong Tavol Machinery Co., Ltd is the leading manufacturer and service provider of
Materials handling products since 2011. Brand with TAVOL, we are specialized in verious types of diesel forklift, electric
forklift, self propelled scissor lift, mobile scissor lift and other material handling equipment. Dedicated to the research and
development of lifting and Materials handling technologies, Adopts innovative ideas and design in developing new products and services. Tavol is designed with good safety, high performance, high operating efficiency, and environmentally friendly lifting platform and forklift. We are committed to helping our customers reduce plant investment, improve production efficiency, reduce routine maintenance, save energy consumption, and achieve the best return on investment. The full range of material handling solutions provide one-stop services such as pre-sale technical support and after-sales service system to relieve customers from worries.We would like to supply the first-class product quality, with our excellent service to meet your demand of the material handling machinery, welcome to choose Tavol Machinery, Sincerely hoping to growth together with you!
Production Process
Customers' Feedback
FAQ
1.Q:What your term of payment?
A:We accept TT, Letter of credit, Online bank payment, Support Alibaba trade insurance etc.
2.Q:How about your delivery time?
A: Lead time 10-15 days for in stock, If need customized, it will take about 20 working days.
3.Q:What is the MOQ?
A: 1 set is okay. More quantity wit nice discount.
4.Q:How long is your product warranty?
A:The product warranty period is 12 months.
5.Q:What should we do if there have quality problems?
A:During warranty period we will provide free spare parts for free.
