2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group

Tavol diesel forklift has more than 20 years production and export experience, loading capacity from 1ton to 7 ton,lifting height from 3 meters to 6 meters,the mast can be two stages ,three stages and container mast.Our standard engine is Chinese Xinchai brand,Japanese Isuzu brand,Mitsubishi brand and Yanmar brand can also can be chosen.We can do hydraulic transmission and mechanical transmission to meet your needs.
Our diesel forklift with fast delivery time(5-7 working days),accept OEM and ODM service.For more details ,welcome to contact with us.
Availability:
Quantity:
2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group
2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group
2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group
2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group
  • CPC/CPCD

  • TAVOL

  • 84272090

Product Description

2.5-5 Ton Diesel LPG Forklift CPCD Series - Tavol Group

Tavol forklift adopts the streamline design that makes the appearance more pleasing,using domestic well-known engine brand which is powerful, dependable, easy to service ,and with low emissions and fuelconsumption.Our forklift can reduce your cost,provide greater productivity and profitability for you.


Technical Specifications:


Model
CPC20/CPCD20
CPC25/CPCD25
CPC32/CPCD32
CPC36/CPCD36
Rated Loading Capacity(kg)
2000
2500
3200
3600
Load Center Distance(mm)
500
500
500
500
Drive Form
Diesel
Diesel
Diesel
Diesel
Max Lifting Speed            (Full load)(mm/h)
400
400
475
450
Max Driving Speed            (Empty/Full load)(km/h)
17/19
17/19
18/20
18/20
Fork Lifting Height(mm)
3000
3000
3000
3000
Mast Tilt Angle                (Forward and Backward)
6°/12°
6°/12°
6°/12°
6°/12°
Min. Turning Radius(mm)
2450
2450
2530
2540
Min. Ground Clearance(mm)
110
110
135
135
 Length (Including Fork)(mm)
3605
3605
3970
4000
Width(mm)
1160
1160
1230
1230
Height(Door Frame Indented)
2095
2095
2110
2110
Max working Height(mm)(Door Frame Out Completely)
4080
4080
4270
4270
Height From Ground to Overhead Guard(mm)
2095
2095
2105
2105
Front Overhang(mm)
451
451
465
465
Wheel Base(mm)
1640
1640
1775
1775
Front Wheel Track(mm)
970
970
1000
1000
Rear Wheel Track(mm)
970
970
970
970
Front Wheel Tyre
7.00-12
7.00-12
28*9-15
25*9-15
Rear  Wheel Tyre
6.00-9
6.00-9
6.50-10
6.50-10
Self Weight(kg)
3320
3600
4250/4290
4660/4700
Fork Width(mm)
122
122
122
122
Fork Thickness(mm)
40
40
45
45
Block Shelf Height
1000
1000
1225
1225
Standard Fork Length(mm)
1070
1070
1220
1220
Engine Rated Power(kw)
36.8
36.8
36.8
36.8
Engine Speed At Rated Power (rmp)
2500
2500
2500
2500
Engine Maximum Torque(Nm)
157
157
156
156
Engine Speed At Maximum Torque(rpm)
1800
1800
1700~1900
1700~1900
Variable speed form
 Mechanical / Hydraulic
 Mechanical / Hydraulic
 Mechanical/ Hydraulic
Mechanical/ Hydraulic

Why Choose Tavol Forklift ?

01- Unrivaled Power: 27% Gradeability Engineered to conquer steep slopes that stop other electric forklifts. We combine zero emissions with internal combustion-level climbing performance.

02- Global Compliance: Multi-Engine Options From high-value brands to Isuzu, Mitsubishi, and Kubota (Euro V/EPA). We provide 100% legal compliance and easy maintenance for any country.

03- Risk-Free Investment: 24-Month Warranty Backed by Stock Code 307262. With our 5-part transparent quotation and 2-year warranty, your capital is secure and your asset maintains high resale value.


Global Service & Certified Quality

01- Certified Compliance: All Tavol equipment is fully CE and ISO certified, meeting the most stringent international safety and performance standards. We ensure your machinery is fully compliant with local regulations in over 120 countries, providing a "passport" for global entry.

02- Global Support Network: Our dedicated service network spans 64 countries, offering professional local technical support, troubleshooting, and maintenance services. You are never alone—wherever your project is, Tavol is there.

03- Rapid Spare Parts Supply: We maintain a comprehensive global supply chain to ensure that critical spare parts are delivered to your site within 48-72 hours, minimizing downtime and maximizing your operational productivity.
