Product Description
SGTN（Stubble rotary tiller）
SGTN series stubble rotary tller with middle gear transmission, it can be mountedwith the tractor 12-120hp. With wide and strong blade, so it can smash straw and suited to hard soil. It is suited to dry land and paddy field.
SGTN main specifications
Model | Matched power(hp) | Working depth(cm) | Working Depth(cm) | No.of knives | Type of knife | Total Weight(kg) | O.D.mm (LxWxH) |
| SGTN-80D | 12-15 | 80 | 8-16 | 16 | SGTN-L | 190 | 850x850x1000 |
| SGTN-100D | 12-15 | 100 | 18-16 | 16 | SGTN-L | 208 | 850x1050x1000 |
| SGTN-115D | 15-18 | 115 | 8-16 | 24 | SGTN-L | 224 | 900x1310x1000 |
| SGTN-120D | 15-18 | 120 | 8-16 | 24 | SGTN-L | 229 | 300x1350x1000 |
| SGTN-125D | 18-20 | 125 | 8-16 | 24 | SGTN-L | 234 | 900x1450x1000 |
| SGTN-140D | 20-25 | 140 | 8-16 | 24 | SGTN-L | 244 | 900x1600x1000 |
| SGTN-150D | 25-30 | 150 | 8-16 | 24 | SGTN-L | 254 | 900x1740x1000 |
| SGTN-160D | 50-55 | 160 | 8-16 | 24 | SGTN-L | 265 | 900x1800x1000 |
| SGTN-180D | 50-55 | 180 | 8-16 | 32 | SGTN-L | 437 | 1020x2056x1152 |
| SGTN-200D | 55-75 | 200 | 8-16 | 32 | SGTN-L | 452 | 1020x2396x1152 |
| SGTN-220D | 60-80 | 220 | 8-16 | 40 | SGTN-L | 475 | 1020x2396x1152 |
| SGTN-250D | 75-90 | 250 | 8-16 | 40 | SGTN-L | 490 | 1020x2816x1152 |
| SGTN-300D | 90-120 | 300 | 8-16 | 56 | SGTN-L | 536 | 1020x3316x1152 |
