Wall Jib Cranes

Jib Crane Wall Type BX Model with 0.5 ton 1ton 2 ton 3 ton 5 ton
BX Model Wall type Jib Cranes
Lift capacity: 0.3- 5t
Arm length: less than 6m
Lift height: less than 12m
Availability:
Quantity:
  • Wall Jib Cranes
  • Tavol
  • 046

Product Description

Wall jib crane is known as, which has a horizontal member (known as jib or boom) that supports a moveable hoist fixed to wall.


Prodcut Introduction:

Wall jib crane is known as, which has a horizontal member (known as jib or boom) that supports a moveable hoist fixed to wall.

The main advantage of using a wall-mounted system is the space-savings that it offers. They don’t require any type of floor or foundation support, and they can also be installed very close to the underside of the lowest ceiling obstruction, providing maximum clearance both under and above the boom.


wall jib



Suitable working conditions:

1- This machine suitable to work in the dock, warehouse, workshop etc Fixed working conditions.

It can work within the 360 degrees to lift, move and materials handling.

2- This type machine is composed by the vertical shaft, revoliving arm, rotating shaft, hoist etc.

The bottom of thevertical shaft is fixed on the concreate base.

Horizontally Rotation of the revoliving arm: Manual, depend on the operator use the human force to push the impending working or self prepared rope etc device. The hoist travel with the right and left straight line on the H beam, use the hoist to lift the heavy materials.

3- This type machine with advantages of the Simple structure, Operate convenience, Turning agile, wide working conditions.





Product Features:

1. Ergonomic design;

2. Increase worker productivity;

3. Reduce workplace injuries;

4. Improve safety.


Prodcut Specification:

SI

Descriptions

Reference Data

1

Lift capacity

0.25-1T

2

Working radius

3-5M

3

Max lifting height

6M

4

Work duty

A3

5

Control method

Pendent control

7

Hook

Forged hook with safety lock

8

Lifting speed

0-8M/Min

9

Cross travelling speed

0-20M/Min

10

Slewing degree

180 degrees

Wall-mounted jib cranes can be designed to mount to a wall or building support column.Product Application:

While these types of jib systems are among the most economical in price and design, the major disadvantage of using a wall-mounted or column-mounted jib crane is that the design does not allow for full 360 degrees of rotation. They also require a column or support capable of withstanding the loads, which typically requires a structural engineering survey and approval prior to installation.
