12m Hydraulic Self Propelled Scissor Man Lift Platform

Self propelled scissor lift is advanced man lift powered by battery, and can self drive freely on ground or slope. This electric scissor lift can be operated by only one person. Suitable for aerial installation, maintenance, clean, and other aerial work.
Lift height:
work height :
platform size:
load capacity:
platform extension size:
Quantity:
  • 12m Hydraulic Self Propelled Scissor Man Lift Platform
  • TAVOL
  • 8428909090

Product Description

1. Product introduction

Self propelled scissor lift is advanced man lift powered by battery, and can self drive freely on

ground or slope. This electric scissor lift can be operated by only one person. Suitable for aerial installation, maintenance, clean, and other aerial work.


2. Product Parameter

Product name

Self Propelled scissor lift

Model

SJYZ0.32-12

Load capacity

320kg

Platform height(A)

12m

Working height

14m

Extended platform(B)

900mm

Machine length(C)

2475mm

Machine height(D)

2542mm

Wheel base(E)

1890mm

Platform size

2260*1130mm

Voltage

220V/50HZ/Single Phase or custom-made

Lift motor

2kw, Switzerland Bucher

Travel speed

3.5km/h

Up/down speed

3-5m/min

Hydraulic oil

32# anti-wear hydraulic oil

Max gradeability

25%

Max working angle

1.5°/3°

Tire

φ381*1270mm

Dimension

2475*1150*2094mm

Weight

2960kg

Battery

American Trojan

Travel motor

American White

Brake

American White


4. Detail picture

1. Control Panel:
Easy control on platform for lifting up/down, moving or steering with speed adjustable.


2. Extendable Table

Extendable table enlarge work range for user, cross over small obstacles.


3.Fodable Guardrails:
Fodable guardrails decrease height of scissor lift when go through small openings.


4. Emergency Decline
Make the platform down when power off suddenly or under emergency situation.




5. Application

Self propelled scissor lift  used for aerial installation maintenance of the working sites,

such as hotels, grand hall, shopping mall, sport stadium, large factory, workshops, warehouse etc.


6. Deliver, shipping and serving

Shipping date: 20 days after advance payment

Package: Packed in 1*20GP container

图片9图片10
